RO4200-1 RO4210-2 Niobium Capillary Tube Throttling And Pressure Increase
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x제품 상세 정보
| 상품 | 니오브 튜브 | 화학 성분 | Nb>=99.95% |
|---|---|---|---|
| 방법 | 전자빔로 제련 | 치수 | ￠3~￠120mm |
| 크기 | 사용자 정의 | 청정 | 99.9%(3n) |
| 기준 | ASTM B393 | 정황 | 진공 소둔 |
| 재료 표준 | ASTM B 365-98 | 기술 | 소결, 단조, 가공 |
| 기술 | CNC 밀링 기계 | 융합의 열 | 26.4KJ/몰 |
| 기화 온도 | 2350℃ (10-4Torr 이하) | 항복 강도 | 73MPa |
| 발견 연도 | 1801 | 원래 장소 | 중국 |
| 비열 용량 | 0.265J/g·K | 등급 | RO4200 |
| 원자 번호 | 41 | 표면 상태 | 청소 또는 검은 색 |
| 처리 | 콜드 롤링 | 제조 표준 | ASTM B392-95 |
| 녹는 점 | 2,468 ° C | 사양 | 사용자 정의 |
| 모양 | 튜브 | 전기 전도성 | 0.0693 10^6/cm |
| 밀도 | 8.57 g/cm³ | 예어 | Niobium 모세관 튜브 |
제품 설명
Introduction
Niobium tube is a kind of pipe used for conveying and transferring materials under special conditions, such as high temperature and high pressure, which is widely used in the nuclear industry, aerospace, shipbuilding, chemical industry, and electronics. Due to niobium's excellent corrosion resistance and high temperature stability, niobium tubes have strong compressive, tensile, fatigue, and heat resistance characteristics, so they are widely used in various high-end fields.
Chemical Composition:
| Chemical(%) | ||||||||||||
| Grade | Main component | Other impurities(≤) | ||||||||||
| Nb | Fe | Si | Ni | W | Mo | Ti | Ta | O | C | H | N | |
| Nb1 | Remainder | 0.004 | 0.004 | 0.002 | 0.005 | 0.005 | 0.002 | 0.05 | 0.015 | 0.004 | 0.0015 | 0.003 |
| Nb2 | Remainder | 0.01 | 0.01 | 0.005 | 0.02 | 0.01 | 0.004 | 0.07 | 0.02 | 0.01 | 0.0015 | 0.008 |
Surface treatment
The surface treatment of niobium tube usually includes mechanical polishing, electrolytic polishing, pickling and sandblasting. Mechanical polishing and electrolytic polishing can improve the surface finish and flatness of the niobium tube, and improve the corrosion resistance of the niobium tube. Pickling and sand blasting can remove impurities such as oil and oxide on the surface of the niobium tube to ensure the cleanliness and flatness of the surface of the niobium tube.
Application of niobium
1, high-temperature alloy;
2, niobium base alloy;
3, steel applications;
4. Electric porcelain;
5. Money;
6. Medical field;
7. Medical field;
8. Aerospace industry
Product photo
